DIMENSIONS AND TÉCNICA TABLE

* minimum measures for transport ** (ø 125/550 mm) *** With hose ø 125 from 630 metres to 670 metres or ø 120 from 650 metres to 700 metres

Standard equipment

Flow-distributor turbine with built-in by-pass
4-speed gearbox with shafts completely in oil bath
PTO for fast hose rewinding
Braking system to unwind the hose with fully automatic operation
Automatic speed compensator according to the hose winding diameter
Anti-slackening hose safety device
Safety device to stop the machine if the hose winds unevenly
Electronic hose rewinding speed measuring device
Digital clock
Worm screw hose turning system with micrometric regulation and double guide
Reel support on ball bearings and lipped retention ring with stainless steel bushing
Self-balancing hydraulically controlled rear anchoring brackets, and hydraulic lift of trolley
Bar base hydraulically controlled through spool valve
Flexible rubber hose to supply the machine, complete with connections
Adjustable trolley track and wheel height
SIME sprinkler with slow return and set of nozzles
Pressure-gauge in glycerine bath on the machine
Pressure-gauge in glycerine bath on the sprinkler (SIME)
Ball joint on sprinkler trolley
Sprinkler trolley ballasts
Adjustable bar eye
Hydraulic spool valve for services
Water inlet on both sides

Optionals
