* minimum measures for transport          ** (ø 125/550 mm)

• Flow-distributor turbine with built-in by-pass
• 4-speed gearbox with shafts completely in oil bath
• PTO for fast hose rewinding
• Braking system to unwind the hose with fully automatic operation
• Automatic speed compensator according to the hose winding diameter
• Anti-slackening hose safety device
• Safety device to stop the machine if the hose winds unevenly
• Electronic hose rewinding speed measuring device
• Digital clock
• Worm screw hose turning system with micrometric regulation and double guide
• Reel support on ball bearings and lipped retention ring with stainless steel bushing
• Frame swivelling on a ball bearing centre plate through 360°
• Self-balancing hydraulically controlled rear anchoring brackets, and hydraulic lift of trolley
• Bar base hydraulically controlled through spool valve
• Flexible rubber hose to supply the machine, complete with connections
• Adjustable trolley track and wheel height SIME sprinkler with slow return and set of nozzles
• Pressure-gauge in glycerine bath on the machine
• Pressure-gauge in glycerine bath on the sprinkler (SIME)
• Ball joint on sprinkler trolley
• Sprinkler trolley ballasts
• Adjustable bar eye
• Hot-dip galvanized structure (painted reel)
• Hydraulic spool valve for services
• Water inlet on both sides
• Hydraulic rotation of turret with additional of an element on the spool valve
• Double axle on rocker arm
