* minimum measures for transport

• Flow-distributor turbine with built-in by-pass.
• 4-speed gearbox with shafts completely in oil bath.
• PTO for fast hose rewinding.
• Braking system to unwind the hose with fully automatic operation.
• Automatic speed compensator according to the hose winding diameter.
• Anti-slackening hose safety device.
• Safety device to stop the machine if the hose winds unevenly.
• Electronic hose rewinding speed measuring device.
• Digital clock.
• Worm screw hose turning system with micrometric regulation and double guide.
• Reel support on ball bearings and lipped retention ring with stainless steel bushing.
• Frame swivelling on a ball bearing centre plate through 360°.
• Automatic trolley lifting at the end of sprinkling by means of VertiLift™ system.
• Hydraulically controlled rear anchoring brackets, independent on both sides.
• Bar base hydraulically controlled through spool valve.
• Flexible rubber hose to supply the machine, complete with connections.
• Adjustable trolley track and wheel height.
• SIME sprinkler with slow return and set of nozzles
• Pressure-gauge in glycerine bath on the machine.
• Pressure-gauge in glycerine bath on the sprinkler (SIME).
• Ball joint on sprinkler trolley.
• Sprinkler trolley ballasts.
• Adjustable bar eye.
• Hot-dip galvanized structure (painted reel).
• Six-lever spool valve on swivelling arm
• Water inlet on both sides.
• Hydraulic rotation of bearing centre plate with six levers
